1. Udhëzime të rëndësishme sigurie
Lexoni të gjitha udhëzimet përpara se të përdorni pajisjen. Ruajeni këtë manual për referencë në të ardhmen. Ndiqni gjithmonë masat themelore të sigurisë për të zvogëluar rrezikun e zjarrit, goditjes elektrike ose lëndimit.
- Sigurohuni që lavatriçja të jetë e tokëzuar siç duhet.
- Do not operate the machine if it is damaged or malfunctioning. Contact customer service.
- Mbajini fëmijët larg pajisjes gjatë përdorimit.
- Mos lani sende që janë ndotur me substanca të ndezshme.
- Shkëputeni pajisjen nga priza përpara se ta pastroni ose të kryeni ndonjë mirëmbajtje.
2. Instalimi dhe konfigurimi
2.1 Shpaketimi
Carefully remove all packaging materials. Inspect the machine for any damage incurred during transit. Retain packaging for potential future transport.
2.2 Kërkesat e vendndodhjes
Place the washing machine on a firm, level surface. Ensure there is adequate space around the machine for ventilation and maintenance. Avoid direct sunlight or excessively humid environments.
Përshkrimi i imazhit: This diagram illustrates the necessary clearance for installation. It shows the product dimensions (57cm depth x 59cm width x 97cm height) and recommends additional space for door frames, entrances, and stairs. For example, an additional 10cm width is required for product dimensions when passing through narrow spaces. For installation, ensure at least 1cm clearance from the left/right wall and 1cm from the rear wall. When opening the top lid, allow 10-15cm clearance above the machine.
2.3 Lidhjet e Ujit dhe të Kullimit
- Connect the water supply hose to the water inlet valve on the back of the machine and to a cold water tap. Ensure connections are tight to prevent leaks.
- Position the drain hose into a standpipe or laundry tub, ensuring it is securely fastened to prevent dislodging during the drain cycle. The drain hose connection should be at least 9cm above the floor.
2.4 Nivelimi i makinës
Përdorni një nivelues për t'u siguruar që makina është në nivel të përsosur. Rregulloni këmbët e nivelimit në pjesën e poshtme të makinës sipas nevojës. Një makinë niveluese zvogëlon dridhjet dhe zhurmën gjatë funksionimit.
3. Udhëzimet e funksionimit
3.1 Paneli i kontrollit Mbiview
Përshkrimi i imazhit: This image shows a close-up of the washing machine's touch control panel. It features an LED display in the center showing remaining time and settings. Buttons for water level, wash, rinse, spin, course selection, power, and start/pause are visible. The panel also indicates the 8.5kg capacity.
3.2 Ngarkimi i rrobave
Open the top lid and load clothes loosely into the tub. Do not overload the machine. For optimal washing performance, ensure clothes can move freely.
Përshkrimi i imazhit: Ky imazh ofron një pamje nga lart poshtë view of the Haier washing machine with its glass lid open, revealing the stainless steel wash tub and the pulsator at the bottom. The control panel is visible at the front.
3.3 Automatic Detergent Dispenser
The machine features an automatic liquid detergent dispenser. Pour liquid detergent into the designated compartment. The machine will automatically dispense the appropriate amount based on the laundry load, eliminating the need for manual measurement each time.
Përshkrimi i imazhit: This image shows a hand refilling the automatic liquid detergent dispenser located on the top edge of the washing machine. The dispenser is a clear, elongated container designed for easy pouring and monitoring of detergent levels.
3.4 Selecting a Wash Course
Turn on the power and select your desired wash course using the control panel. The machine offers various programs tailored for different fabric types and washing needs.
Përshkrimi i imazhit: This image displays a list of available wash courses for the Haier washing machine, including Standard A (daily wash), Standard B (single rinse), My Flow (custom settings), Careful (for jeans and thick items), Quick (for lightly soiled items), Blanket, Tub Air Dry, Fragrance Up (to enhance fabric softener scent), Dry (for delicate items), and Tub Cleaning.
Kurse të disponueshme:
- Standardi A: Për larjen e përditshme të rrobave.
- Standardi B: For everyday laundry with a single rinse.
- My Flow: Allows you to save and use your preferred custom settings.
- Kujdes: Suitable for washing items like jeans and thick fabrics.
- Shpejt: A 10-minute cycle for lightly soiled items, reducing household chores. (Max 2.0kg load)
- Batanije: For washing blankets and large items.
- Tub Air Dry: Reduces drying time and is ideal for indoor drying.
- Fragrance Up: Ensures fabric softener scent adheres evenly to clothes, enhancing the fragrance effect.
- E thatë: Për sendet delikate.
- Pastrimi i vaskës: For regular cleaning of the wash tub.
3.5 Fillimi i Ciklit të Larjes
Press the Start/Pause button to begin the selected wash cycle. The machine will automatically fill with water, dispense detergent, wash, rinse, and spin.
3.6 Karakteristika të veçanta
- High Concentration Spiral Wash: Creates a high-concentration detergent solution and powerful spiral water flow to effectively remove dirt.
- Wrinkle-Reducing Spin: Adjusts spin time and rotation speed to minimize wrinkles, reducing ironing time. (Max 1.0kg load)
- DD Inverter Motor: Direct drive inverter motor ensures low noise and low vibration operation, allowing for quiet washing even at night.
Përshkrimi i imazhit: This image highlights the washing machine's high cleaning power. It shows a shirt being washed in a powerful spiral water flow, alongside diagrams of the high-concentration spiral wash, 3D wing pulsator, and checkered tank design, all contributing to effective dirt removal.
Përshkrimi i imazhit: This diagram illustrates the internal structure of the DD Inverter motor, emphasizing its benefits: low noise, low vibration, and energy saving. It explains that the direct connection to the wash tub and precise control of rotation speed and friction contribute to reduced energy consumption.
4. Mirëmbajtja dhe Pastrimi
Mirëmbajtja e rregullt siguron performancë optimale dhe zgjat jetëgjatësinë e lavatriçes suaj.
4.1 Pastrimi i vaskës
Use the 'Tub Cleaning' course regularly to prevent mold and mildew buildup in the wash tub. The 'Quick Tub Cleaning' function takes approximately 2 minutes and is recommended after each wash cycle to suppress mold growth.
Përshkrimi i imazhit: This image shows the interior of the washing machine tub during a 'Quick Tub Cleaning' cycle, with water swirling inside. A timer indicating '2 minutes' is overlaid, highlighting the short duration of this maintenance function.
4.2 Pastrimi i Dispensatorit të Detergjentit
The automatic liquid detergent dispenser tank (approx. 540ml capacity) is removable for easy cleaning. Periodically remove and rinse it thoroughly to prevent residue buildup.
4.3 Pastrimi i Filtrit të Fijeve
Regularly clean the lint filter to ensure efficient lint removal and prevent drainage issues. Refer to the diagram in the full manual for filter location and removal instructions.
4.4 Pastrimi i jashtëm
Wipe the exterior of the machine, including the glass top, with a soft, damp cloth. The flat glass top design makes cleaning easy.
5. Troubleshooting
Përpara se të kontaktoni shërbimin ndaj klientit, referojuni problemeve dhe zgjidhjeve të zakonshme të mëposhtme:
| Problem | Shkaku i mundshëm | Zgjidhje |
|---|---|---|
| Makina nuk fillon | Power cord unplugged, lid not closed, water supply off. | Check power connection, ensure lid is fully closed, open water tap. |
| Dridhje/zhurmë e tepërt | Machine not level, overloaded, foreign objects in tub. | Level the machine, reduce load, check for and remove foreign objects. |
| Rrjedhje uji | Loose hose connections, clogged drain hose. | Shtrëngoni lidhjet e tubit, pastroni tubin e kullimit. |
| Detergjenti nuk shpërndahet | Dispenser tank empty, clogged dispenser. | Refill dispenser, clean dispenser tank. |
6. Specifikimet e produktit
- Marka: Haier
- Numri i modelit: JW-KD85B
- Dimensionet e Produktit (Th x G x L): 57 cm x 59 cm x 97 cm
- Kapaciteti: 8.5 kg
- Pesha e artikullit: 40 kg
- Ngjyra: E bardha
- Vëlltage: 100 V (AC)
- Niveli i zhurmës: 38 dB
- Lloji i kontrollit: Touch Screen (LED Display)
- Mënyra e funksionimit: Plotësisht Automatik
- Numri i Programeve: 13
- Karakteristikat e veçanta: Inverter, Start Reservation Timer, Child Lock, Drum Clean, Automatic Detergent Dispenser
- Materiali i vaskës: Çelik inox
- Komponentët e përfshirë: Magic hose connection (1), Bottom cover (with 1 screw), Liquid detergent auto dispenser tank (1), Water supply hose (1)
7. Informacioni i garancisë
This Haier washing machine (Model JW-KD85B) comes with a Garanci 1-vjeçare e prodhuesit from the date of purchase. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. For detailed terms and conditions, refer to the warranty card included with your product or contact Haier customer support.
8. Mbështetja e klientit
For any inquiries, technical assistance, or service requests, please contact Haier customer support. Haier offers comprehensive after-sales service across Japan.
Përshkrimi i imazhit: This image highlights Haier's nationwide after-sales service in Japan, available 365 days a year. It shows icons representing nationwide coverage across 47 prefectures and a 365-day reception service, indicating support from Haier Aqua Service and Haier Customer Center for repairs and consultations.
Haier Customer Center: Available 365 days a year for consultations and repairs.
Please visit the official Haier website or refer to the contact information provided in your product documentation for the most up-to-date support details.
